Polyga H3 3D Scanner

The Polyga H3 is simply an all-round professional handheld 3D scanner that’s easy to use, portable, and high-accuracy—all at an affordable price.

BUILT FOR AGILITY

The Polyga H3 is powered by FlexScan3D 3D scanning software that powers all Polyga's stationary 3D scanners. The software also works seamlessly with the H3. FlexScan3D’s high-processing speed from capture to post-processing delivers a responsive and seamless 3D scanning experience.

ACHIEVE BETTER RESULTS

The H3 uses proprietary multi-image scanning patterns to capture 3D scans. That’s why the quality of the H3 single 3D scan is better when compared to other systems in its class. You can see the difference.

VERSATILITY AT ITS CORE

The Polyga H3 scans objects into digital 3D models from 10 cm to 1.8 m in length. Scan a variety of objects from artifacts, mechanical parts, faces, and even the entire body for industry applications including manufacturing, arts, archaeology, medic

AUTOMATE 3D SCANNING

Transform from a handheld into a plug and play stationary 3D scanner. Simply mount the scanner on a tripod and use an optional rotary table for automated 3D scanning. It’s completely handsfree and there’s no need for calibration. Set up the scanner and let the system do all the work for you.

GET IT IN COLOR

The Polyga H3 is also available in color to capture color scans when high-quality color and texture information are important.

Best In Class

Leveraging the technology and experience in developing Polyga’s stationary 3D scanning systems, the H3 produces one of the highest accuracy in a single-shot scan for a handheld system in its class.

Versatility At Its Core

Powered by duo industrial-grade cameras at an ultra-high speed of 700 frames per second, the Polyga H3 handheld 3D scanner captures objects into complete digital 3D models in minutes. Scan a variety of objects from artifacts, mechanical parts, faces, and even the entire body for work applications in industries including manufacturing, arts, archaeology, medical, computer vision, research, and design. You have the power to accomplish your scanning projects in less time.

Polyga H3 Scans Objects into Digital 3D Models from 10 cm to 1.8 m in Length

H3
H3 scan samples

Reasons You’ll Love the H3

H3 scan

Handheld

The H3 is a point and shoot system. Move around the physical object to capture it into digital form. It’s convenient to use and super portable to take on off-site projects.

H3 scan

High-Accuracy

The H3 handheld 3D scanner produces up to 1.5 million points per scan with an accuracy of up to 80 microns (0.08 mm) per scan.

H3 scan

Hybrid

The H3 pushes the boundaries of what it truly means to be a hybrid system. It captures extremely high-accuracy data in a single scan in both handheld and stationary modes.

Technical Specifications

Cameras 2 x 700 FPS – Monochrome or Color Cameras
Point-to-Point Spacing 0.5mm or better
Data acquisition speed (points per second) Up to 1.5 million
Mesh Frames Per Second 5
Scanning Technology Structured light
Dimension (mm) 280 x 200 x 60
Weight (kg) 1.1
Field of View (mm) 205 x 112 to 455 x 252
Depth of Field (mm) 250
Accuracy (μm) 80
Standoff distance (mm) 380
Scanning Software FlexScan3D
Geometry Formats PLY, OBJ, STL, ASC, FBX, 3D3
Minimum Computer Requirements Windows 10 (64-bit) Operating System, Intel Core i5 CPU or better, 16 GB Memory or greater, 512 MB Video Card, 250 GB free disk space or more

See The Fine Details

The Polyga H3 handheld 3D scanner gets the tiniest of details, even wrinkles on a jacket, to ensure your digital 3D models are captured in the true likeness of the real-world object.

real object 3d scan
